Pneumatic Torque Multipliers - PneuTorque 108 Diameter

Based on the original PneuTorque the 'Standard Series' range is a direct result of years of refinement and development necessary to keep pace with industry's requirements today. All models are available fitted with a remote motor which have no direction shut-off but rely on external pneumatic circuitry to provide this function.

Models available for almost every bolting application, up to 100,000 Nm.  Stall control gives repeatability of +/-5% on a given joint.

Torque Transducers are available to give repeatability of +/-1%.

16031 PT1 3/4"            16031.MTS PT1 MTS 3/4"                     16031.AUT PT1 AUT 3/4"          16011 PT1 1"

16031

PT1, 3/4"

120.00 - 500.00 ft. lbs

160.00 - 680.00 Nm

16.00 - 69.00 kgf·m

16031.MTS

PT1 MTS, 3/4"

120.00 - 500.00 ft. lbs

160.00 - 680.00 Nm

16.00 - 69.00 kgf·m

16031.AUT

PT1 AUT, 3/4"

120.00 - 500.00 ft. lbs

160.00 - 680.00 Nm

16.00 - 69.00 kgf·m

16011

PT1, 1"

120.00 - 500.00 ft. lbs

160.00 - 680.00 Nm

16.00 - 69.00 kgf·m

           16011.MTS PT1 MTS 1"         16011.AUT PT1 AUT 1" 16098 PT1A 3/4" 16098.MTS PT1A MTS 3/4"

16011.MTS

PT1 MTS, 1"

120.00 - 500.00 ft. lbs

160.00 - 680.00 Nm

16.00 - 69.00 kgf·m

16011.AUT

PT1 AUT, 1"

120.00 - 500.00 ft. lbs

160.00 - 680.00 Nm

16.00 - 69.00 kgf·m

16098

 PT1A, 3/4"

200.00 - 900.00 ft. lbs

270.00 - 1200.00 Nm

27.00 - 125.00 kgf·m

16098.MTS

PT1A MTS, 3/4"

200.00 - 900.00 ft. lbs

270.00 - 1200.00 Nm

27.00 - 125.00 kgf·m

16098.AUT PT1A.AUT 3/4" 16097 PT1A 1" 16097.MTS PT1A MTS 1" 16097.AUT PT1A AUT 1"

16098.AUT

PT1A AUT, 3/4"

295.00 - 900.00 ft. lbs

400.00 - 1200.00 Nm



16097

PT1A, 1"

200.00 - 900.00 ft. lbs

270.00 - 1200.00 Nm

27.00 - 125.00 kgf·m

16097.MTS

PT1A MTS, 1"

200.00 - 900.00 ft. lbs

270.00 - 1200.00 Nm

27.00 - 125.00 kgf·m

16097.AUT

PT1A AUT, 1"

295.00 - 900.00 ft. lbs

400.00 - 1200.00 Nm



16008 PT2 3/4" 16008.AUT PT2 AUT 3/4" 16013 - PT2, 1in. 380.0 - 1250.0 lbf·ft 515.0 - 1700.0 Nm 52.0 - 170.0 kgf·m 16013.MTS - PT2.MTS, 1in. 380.0 - 1250.0 lbf·ft 515.0 - 1700.0 Nm 52.0 - 170.0 kgf·m

16008

PT2, 3/4"

380.00 - 1250.00 ft. lbs

515.00 - 1700.00 Nm

52.00 - 170.00 kgf·m

16008.AUT

PT2 AUT, 3/4"

380.00 - 1250.00 ft. lbs

515.00 - 1700.00 Nm

52.00 - 170.00 kgf·m

16013

PT2, 1"

380.00 - 1250.00 ft. lbs

515.00 - 1700.00 Nm

52.00 - 170.00 kgf·m

16013.MTS

PT2 MTS, 1"

380.00 - 1250.00 ft. lbs

515.00 - 1700.00 Nm

52.00 - 170.00 kgf·m

16013.AUT PT2 AUT 1" 16013.HD - PT2, HD, 1in. 380.0 - 1250.0 lbf·ft 515.0 - 1700.0 Nm  52.0 - 170.0 kgf·m 16015 - PT5, 1in. 650.0 - 2500.0 lbf·ft 880.0 - 3400.0 Nm 90.0 - 345.0 kgf·m 16015.MTS PT5 MTS 1"

16013.AUT

PT2 AUT, 1"

516.00 - 1250.00 ft. lbs

700.00 - 1700.00 Nm

16013.HD

PT2, HD, 1"

380.00 - 1250.00 ft. lbs

515.00 - 1700.00 Nm

52.00 - 170.00 kgf·m

16015

PT5, 1"

650.00 - 2500.00 ft. lbs

880.00 - 3400.00 Nm

90.00 - 345.00 kgf·m

16015.MTS

PT5 MTS, 1"

650.00 - 2500.00 ft. lbs

880.00 - 3400.00 Nm

90.00 - 345.00 kgf·m

16015.AUT PT5 AUT 1" 16017 - PT6, 1 1-2in. 650.0 - 2500.0 lbf·ft 880.0 - 3400.0 Nm 90.0 - 345.0 kgf·m 16017.MTS PT6 MTS 1 1/2" 16017.AUT PT6 AUT 1 1/2"

16015.AUT

PT5 AUT, 1"

650.00 - 2500.00 ft. lbs

880.00 - 3400.00 Nm

90.00 - 345.00 kgf·m

16017

PT6, 1 1/2"

650.00 - 2500.00 ft. lbs

880.00 - 3400.00 Nm

90.00 - 345.00 kgf·m

16017.MTS

PT6 MTS, 1 1/2"

650.00 - 2500.00 ft. lbs

880.00 - 3400.00 Nm

90.00 - 345.00 kgf·m

16017.AUT

PT6 AUT, 1 1/2"

650.00 - 2500.00 ft. lbs

880.00 - 3400.00 Nm

90.00 - 345.00 kgf·m

16066 - PT7, 1 1-2in. 1300.0 - 4500.0 lbf·ft 1762.0 - 6000.0 Nm 180.0 - 620.0 kgf·m 16066.MTS - PT7.MTS, 1 1-2in. 1300.0 - 4500.0 lbf·ft 1762.0 - 6000.0 Nm 180.0 - 620.0 kgf·m 16066.AUT - PT7.AUT, 1 1-2in. 1622.0 - 4500.0 lbf·ft 2200.0 - 6000.0 Nm 16072 - PT9, 1 1-2in. 2000.0 - 7000.0 lbf·ft 2710.0 - 9500.0 Nm 275.0 - 965.0 kgf·m

16066

PT7, 1 1/2"

1300.00 - 4500.00 ft. lbs

1762.00 - 6000.00 Nm

180.00 - 620.00 kgf·m

16066.MTS

PT7 MTS, 1 1/2"

1300.00 - 4500.00 ft. lbs

1762.00 - 6000.00 Nm

180.00 - 620.00 kgf·m

16066.AUT

PT7 AUT, 1 1/2"

1622.00 - 4500.00 ft. lbs

2200.00 - 6000.00 Nm



16072

PT9, 1 1/2"

2000.00 - 7000.00 ft. lbs

2710.00 - 9500.00 Nm

275.00 - 965.00 kgf·m

16072.MTS - PT9.MTS, 1 1-2in. 2000.0 - 7000.0 lbf·ft 2710.0 - 9500.0 Nm 275.0 - 965.0 kgf·m 16072.AUT - PT9.AUT, 1 1-2in. 2286.0 - 7000.0 lbf·ft 3100.0 - 9500.0 Nm 16046 - PT11, 2 1-2in. 3250.0 - 14700.0 lbf·ft 4400.0 - 20000.0 Nm 450.0 - 2000.0 kgf·m 16046.MTS PT11 MTS 2 1/2"

16072.MTS

PT9 MTS, 1 1/2"

2000.00 - 7000.00 ft. lbs

2710.00 - 9500.00 Nm

275.00 - 965.00 kgf·m

16072.AUT

PT9 AUT, 1 1/2"

2286.00 - 7000.00 ft. lbs

3100.00 - 9500.00 Nm



16046

PT11, 2 1/2"

3250.00 - 14700.00 ft. lbs

4400.00 - 20000.00 Nm

450.00 - 2000.00 kgf·m

16046.MTS

PT11 MTS, 2 1/2"

3250.00 - 14700.00 ft. lbs

4400.00 - 20000.00 Nm

450.00 - 2000.00 kgf·m

18086 PT12 2 1/2" 18086.MTS - PT12 MTS 2 1-2in. 7000.0 - 25000.0 lbf·ft 9500.0 - 34000.0 Nm 16052 PT13 2 1/2" 16052.MTS PT13 MTS 2 1/2"

18086

PT12, 2 1/2"

7000.00 - 25000.00 ft. lbs

9500.00 - 34000.00 Nm



18086.MTS

PT12 MTS 2 1/2"

7000.00 - 25000.00 ft. lbs

9500.00 - 34000.00 Nm



16052

PT13, 2 1/2"

10000.00 - 35000.00 ft. lbs

13550.00 - 47000.00 Nm

1380.00 - 4840.00 kgf·m

16052.MTS

PT13 MTS, 2 1/2"

10000.00 - 35000.00 ft. lbs

13550.00 - 47000.00 Nm

1380.00 - 4840.00 kgf·m

16045 PT14 3 1/2" 16045.MTS - PT14.MTS, 3 1-2in. 16500.0 - 73500.0 lbf·ft 22375.0 - 100000.0 Nm 2280.0 - 10000.0 kgf·m 18089.MTS PT15 MTS 18090.MTS PT16 MTS

16045

PT14, 3 1/2"

16500.00 - 73500.00 ft. lbs

22375.00 - 100000.00 Nm

2280.00 - 10000.00 kgf·m

16045.MTS

PT14 MTS, 3 1/2"

16500.00 - 73500.00 ft. lbs

22375.00 - 100000.00 Nm

2280.00 - 10000.00 kgf·m

18089.MTS

PT15 MTS

29500.00 - 110500.00 ft. lbs

40000.00 - 150000.00 Nm

4079.00 - 15296.00 kgf·m

18090.MTS

PT16 MTS

40500.00 - 147500.00 ft. lbs

55000.00 - 200000.00 Nm

5608.00 - 20394.00 kgf·m

18090.MTS PT17 MTS

18090.MTS

PT17 MTS

51500.00 - 184500.00 ft. lbs

70000.00 - 250000.00 Nm

7138.00 - 25493.00 kgf·m
