Electrode Wrenches

Electrode Torque Wrenches are for torque tightening of carbon electrodes up to 3200 Nm.

The 8" diameter electrode wrench uses the professional torque handle as the control mechanism, above 8" use the Industrial torque wrench.

The correct tightening of carbon/graphite electrodes is known to increase the energy efficiency of electric arc furnaces and prevents electrode sections from being lost in the furnace.

Norbar Electrode wrenches are based on two well proven torque wrench designs; electrodes up to 8 inches use the 'Professional' type, 9 inches and upwards are based on the 'Industrial' wrench. Positive torque control increases the energy efficiency.  Self-clamping action speeds the tightening operation.  Unmistakable signal when the set torque is reached. A wide range of electrode sizes can be tightened.

12506 - 8" Electrode 12530 - 10" Electrode 12531 - 12" Electrode TWCS Watermark

12506 - 8" Electrode

33.0 - 230.0 lbf·ft

44.0 - 312.0 Nm

12530 - 10" Electrode

110.0 - 400.0 lbf·ft

146.0 - 542.0 Nm

12531 - 12" Electrode

150.0 - 575.0 lbf·ft

205.0 - 780.0 Nm

12532 - 14" Electrode (High)

260.0 - 840.0 lbf·ft

350.0 - 1140.0 Nm

TWCS Watermark 12535 - 18" Electrode (high) 12536 - 20" Electrode (High) 12537 - 22" Electrode (High)

12533 - 16" Electrode (High)

260.0 - 950.0 lbf·ft

350.0 - 1300.0 Nm

12535 - 18" Electrode (High)

550.0 - 1110.0 lbf·ft

750.0 - 1500.0 Nm

12536 - 20" Electrode (High)

750.0 - 1475.0 lbf·ft

1000.0 - 2000.0 Nm

12537 - 22" Electrode (high)

900.0 - 1750.0 lbf·ft

1200.0 - 2370.0 Nm

12538 - 24" Electrode (High) 12538.HD - 24" Electrode (heavy duty)

12538 - 24" Electrode (High)

900.0 - 1750.0 lbf·ft

1200.0 - 2370.0 Nm



12538.HD - 24" Electrode

(heavy duty)

1200.0 - 2360.0 lbf·ft

1600.0 - 3200.0 Nm
